SounDigital 1200.4-2 EVOPS 2 ohm
EAN: 7898644524111
SD1200.4-2 EVOPS
SD1200.4-2 Power Sports amplifier
Read More
899,00 €
Description
Specifications
Manuals
For use in Power Sports projects, the 1200.4 EVOPS is a compact, modern design amplifier that delivers 1200W RSM of power distributed over 4 channels.
The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for projects in water, clay and other Power Sports settings.
The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for projects in water, clay and other Power Sports settings.
Power @ 1Ω: 4 X 300W RMS
Power @ 2Ω: 4 X 198W RMS
Power @ 4Ω: 4 X 130W RMS
Operating Voltage:
8V – 16V
Current Draw (Music):
49A
Current Draw (Max):
99A
Recommended Fuse (Music):
60A
Total Efficiency:
84%
Damping Factor:
200
Frequency Response (-3dB):
5Hz – 22kHz
SNR:
88dB
Crossover
LPF / HPF: 45Hz – 850Hz
Width:
5.8 in / 14,9 cm
Length:
6.5 in / 16,6 cm
Height:
2.4 in / 6,2 cm
Weight:
1,27 Kg.
