Match PP 86DSP MK2

MATCH PP 86DSP MK2
Plug & Play Power for Multi-Channel Factory Sound Systems
The MATCH PP 86DSP MK2 seamlessly continues the successful story of its predecessor while implementing several upgrades. As a high-performance 8-channel amplifier with a 1-channel line output and an integrated 9-channel DSP with 64 Bit power, it’s perfectly suited for audiophile upgrades of multi-channel factory sound systems, conveniently providing an impressive sound experience.

Seamless Integration and Impressive Connectivity
The MATCH Plug & Play concept ensures seamless integration with factory systems, which was uncompromisingly realized in the PP 86DSP MK2. With its impressive 2 Ohms stability across all amplifier channels, it effortlessly connects to nearly all OE speakers, while optional cable harnesses significantly facilitate integration into existing multi-channel factory sound systems. Furthermore, the MATCH PP 86DSP MK2 boasts enhanced connectivity, featuring an intelligent 6-channel highlevel input with the ADEP.3 circuit and a MEC slot for system expansions such as Bluetooth® HD audio streaming. It also includes a 1-channel mono line output for connecting external amplifiers like the MATCH UP 1FX and an optical input in SPDIF format with a sampling rate between 12 and 96 kHz. Last but not least, it also comes with our SCP port for optional accessories like the DIRECTOR, CONDUCTOR etc.

Virtual Channel Processing – The Modern Way of Signal Routing
The optimal adaptation to existing multi-channel sound systems requires sensible management and configuration of the many DSP channels – so it was no question that the PP 86DSP MK2 is also equipped with Audiotec Fischer′s innovative virtual channel processing. Especially when front, rear and center systems are split into multi-way systems, conventional routing concepts quickly reach their limits, both in terms of implementation and usability. The multi-stage ″Virtual Channel Processing″, in conjunction with the recognized user-friendly DSP PC-Tool software makes it easy to map even highly complex system configurations and to freely assign our proprietary FX sound features. Additionally, thanks to its generous number of channels in combination with the optional MEC ANALOG IN module, the PP 86DSP MK2 is also a prime example for applications where 1 to 1 routing (IOR) makes sense.

ACO – Advanced 32 Bit CoProcessor Plattform
Of course, the PP 86DSP MK2 is equipped with our proprietary 32 Bit ACO platform, which doesn’t just take over all control tasks ultra-fast, but also handles a bunch of audio functions: fantastic sound effects such as Augmented Bass Processing or Real Center are implemented as well as a channel-separated Input EQ including Input Signal Analyzer (ISA) for easy analysis and compensation of input signals of OE radios, which already include a sound setup by default.

DSP PC-Tool 5 feat. TuneEQ – Powerful features for the ultimate sound experience
Of course, the MATCH PP 86DSP MK2 can be easily configured via our professional and exceptionally intuitive DSP PC-Tool 5. The familiar, numerous setting options leave nothing to be desired and guarantee an extremely precise sound adjustment even for complex system configurations. And thanks to the proprietary TuneEQ function for automated frequency response correction, you also save a lot of time when optimizing your sound.
