Ground Zero GZUA 4SQ
EAN: 4037072024609
GZUA 4SQ
4-Channel SQ Amplifier
4 x 185 or 2 x 440W
wide bandwidth hpf / lpf filters
Ultimate sound quality
Adjustable BIAS setting
Read More
699,00 €
Description
Specifications
Ground Zero Uranium 4-channel high-end class A/B SQ amplifier. 2 ohms stable (stereo operation) Adjustable BIAS setting Adjustable high and low pass filters with wide bandwidth Bandpass function with activated high and low pass filter Adjustable input sensitivity Power on delay Temperature / short circuit / overload protection
4-channel high-end class AB amplifier
High-performance 4-channel SQ amplifier
Output power:
- 4x 115 W RMS @ 4 ohms
- 4x 185 W RMS @ 2 ohms
- 2x 440 W max. @ 4 ohms (bridged)
2 ohms stable (stereo operation)
THD+N 0.01%
Frequency Response 10 Hz - 70kHz ( -3dB )
LPF: 20 Hz - 400 Hz / 200 - 4000 Hz ( x10 )
HPF: 20 Hz - 400 Hz / 200 - 4000 Hz ( x10 )
Band Pass Filter 20 Hz - 4000Hz ( x10 )
SNR: 110dB
Damping Factor: 800
Adjustable BIAS setting
Adjustable high and low pass filters with wide bandwidth
Bandpass function with activated high and low pass filter
Adjustable input sensitivity
Power on delay
Temperature / short circuit / overload protection
Dimensions:
209 x 48 x360 mm
