DD Audio SS4.1300
SS4.1300-12V
4-Channel amplifier
D class amplifier
Very small size
Efficient heat sink
4 x 325W / 2 x 650W
Read More
349,00 €
Description
Specifications
The new SS4.1300 brings next level power to the multi-channel wing of the SS Series amplifier line-up. With nearly 200 watts per channel at 4 Ohms and over 325 Watts at 2 Ohms, these compact amps will drive pro audio and motorcycle systems to new extremes with exceptional sound quality.
The SS amplifiers quickly earned a reputation for big clean power from a small package. Their high speed, high current class D designs offer high power and superior sound quality in compact footprints. The classic DD AUDIO style heat sink provides max cooling thanks to 50% more side wall thickness than industry norms with extra long fins to increase surface area. As with all DD amps, all major components are name brands use higher current mosfets and output devices, increased power capacitors, a more powerful transformer, plus improved venting and PCB with twice the thermal capability.
These new high-end mini amps are state of the art, no compromise designs yielding the best sound with unparalleled power to size ratio. The transformation is physically tangible and audibly undeniable.
The SS amplifiers quickly earned a reputation for big clean power from a small package. Their high speed, high current class D designs offer high power and superior sound quality in compact footprints. The classic DD AUDIO style heat sink provides max cooling thanks to 50% more side wall thickness than industry norms with extra long fins to increase surface area. As with all DD amps, all major components are name brands use higher current mosfets and output devices, increased power capacitors, a more powerful transformer, plus improved venting and PCB with twice the thermal capability.
These new high-end mini amps are state of the art, no compromise designs yielding the best sound with unparalleled power to size ratio. The transformation is physically tangible and audibly undeniable.
Operating Voltage: 9 - 16
Test Voltage: 14.4
Input Channel(s): 4
Output Channel(s): 4
Continuous Wattage @4ohm: 180 x 4 / 650 x 2
Continuous Wattage @2ohm: 325 x 4
Max Current Draw (Amps): 150
RCA Input Voltage Sensitivity: 6 - 0.25
High-Level Input Voltage Sensitivity: 20 - 1.1
RCA Input S/N: 95
Damping Factor: 100
THD: 1.0%
Frequency Response (Hz): 20 - 20k
High Pass Filter: 35 - 600
Low-Pass Filter: 35 - 600
Power Wire Gauge: 4
Speaker Wire Gauge: 14
Dimensions (Inches): 6.25 x 4.6 x 2
Dimensions (MM): 159 x 117 x 50
Test Voltage: 14.4
Input Channel(s): 4
Output Channel(s): 4
Continuous Wattage @4ohm: 180 x 4 / 650 x 2
Continuous Wattage @2ohm: 325 x 4
Max Current Draw (Amps): 150
RCA Input Voltage Sensitivity: 6 - 0.25
High-Level Input Voltage Sensitivity: 20 - 1.1
RCA Input S/N: 95
Damping Factor: 100
THD: 1.0%
Frequency Response (Hz): 20 - 20k
High Pass Filter: 35 - 600
Low-Pass Filter: 35 - 600
Power Wire Gauge: 4
Speaker Wire Gauge: 14
Dimensions (Inches): 6.25 x 4.6 x 2
Dimensions (MM): 159 x 117 x 50
