Soundigital 8000.1 EVOX 2 Ohm
EAN: 7898644522582
SD8000.1-2 EVOX
Mono amplifier
8920W
2 Ohm model
Excellent price / quality ratio!
Read More
1 199,00 €
Description
Specifications
The EVO X Line brings the latest technology in a compact design with the highest quality components. From a pioneering technology, SounDigital brought to car audio amplifiers something that had not been explored yet. The thermal coupling through RTGP system. The exclusive RTGP system (Thermal Recovery for power generation) assures SounDigital products both greater thermal efficiency and robustness with higher stability.
Compatible with SD-RLC Remote level control.
Power @ 12.6V @ 4Ω: 1 X 5280 WRMS
Power @ 12.6V @ 2Ω: 1 X 8000 WRMS
Power @ 12.6V @ 1Ω: N/A
Bridge Power @ 12.6V @ 4Ω: N/A
Bridge Power @ 12.6V @ 2Ω: N/A
Power @ 14.4V @ 4Ω: 1 X 5887 WRMS
Power @ 14.4V @ 2Ω: 1 X 8920 WRMS
Power @ 14.4V @ 1Ω: N/A
Bridge Power @ 14.4V @ 4Ω: N/A
Bridge Power @ 14.4V @ 2Ω: N/A
Operating Voltage: 8V – 16V
Current Draw (Music): 402 A
Current Draw (Max): 804 A
Recommended Fuse (Music): 500 A
Total Efficiency: 79%
Damping Factor: 1000
Frequency Response (-3dB): 5Hz – 500Hz
SNR: 82dB
Crossover HPF: 5Hz – 30Hz
Crossover LPF: 50Hz – 500Hz
THD + N (10% Rated Power): 0.08%
Product Dimensions: 13.9 x 8.8 x 2.8 in
Product Dimensions: 35.4 x 22.5 x 7.1 cm
Älä kytke vahvistinta alle nimelliskuorman!
Do not run your amp under rated impedance!.
